Description
Charge outputs;3
Input voltage range
90;– 260 V AC / 50;– 60 Hz
End-of-charging voltage
28.8 – 29.4;V DC
Float charging voltage
27.6 V DC
Recommended battery capacity
75 – 300;Ah
U0 phase limited at
8 h or 16 h
Efficiency
up to 92%
Max. charging current
25 A
Operating temperature
-20 °C;to +50 °C
System
6-stage charging characteristicsOverload and short circuit protectionSleep mode using the remote control or dip switch on the deviceType of protection equivalent to IP 21
Dimensions (W;x;H;x;D)
208.5 x;75 x;283 mm
Weight (approx.)
2.9 kg
Test mark
CE, e-certified (Automotive EMC Directive)
;
- Compact design, low weight
- Series-standard bus interface
- 6-stage IU0U curve, optimised for charging wet, gel and AGM batteries
- Quick charging without power fluctuations
- Sleep mode
